High capacity & easy operation stenter machine for woven fabric

Basic Information
Place of Origin: CHINA
Brand Name: SUNWIN
Certification: CE
Model Number: STH-2600-8
Minimum Order Quantity: 1 SET
Price: USD5000-300000
Packaging Details: Standard Export Packing
Delivery Time: 90 Days
Payment Terms: L/C, T/T
Supply Ability: 8 SETS/ MONTH
Detail Information
Condition: NEW Product: After Rotary Printing Machine Fabric Hot Air Heat Setting Machine
Power: 185 KW Voltage: 380V/50HZ
Color: Blue+ White Weight: 50T
Warranty: 1 Year Service: After Sales Service Provide
High Light:

2400mm rotary printing on fabric

,

8 chamber rotary printing on fabric

,

100m/min Fabric Heat Setting Machine


Product Description

After rotary printing machine fabric hot air heat setting machine



Features:

- Left chain and right chain have individual motor with inverter speed control

- Individual air nozzles with more efficiency and energy saving finishing result

- Air nozzle are easily installing, which suitable for dust remove and maintenance

- Different kinds of nozzles can be used for differnet kinds of fabric finishing.



Specification:

Model STH-2600-8
Machine width 2600mm
Working width 2400mm
Chamber 8 chamber
Speed 5-100m/min
Chain Horizontal pin chain
Heating system Natural Gas Or Thermal Oil
Entry Horizontal type entry device
Padder Horizontal type 2 roller padder
Operation system 15'' Touch Screen Controller
Insulation panel 150mm
Cooling Air cooling device





























High capacity & easy operation stenter machine for woven fabric 0



Company Information:

Wuxi Xinwen Machinery Manufacturing Co., Ltd is a high tech enterprise, specialist in stenter machine design, manufacturing and sales. Since 2000, we start and insist on giving a professional textile machinery solution for our customer, upgrade the product quality and create values for our customer.
