Condition: | NEW | Product Name: | Stenter Machine |
---|---|---|---|
Application: | Printed Fabric, Dyeing Fabric , Raw Fabric Etc | Voltage: | 380V/50HZ |
Power: | 185 KW | Speed: | 5-100m/min |
Air Flow: | Individual Air Flow For Upper And Lower Layer | Weight: | 50 T |
High Light: | 5m/Min fabric printing machine,100m/Min fabric printing machine,textile stenter machine 50T |
After printing machine fabric drying stenter machine
Features:
- Thermal oil, steam or gas heating system for option
- Each chamber equipped with 2x7.5KW circulation fan
- Individual temperature adjustment for each chamber
- Seperately controlled air circulation for upper and lower nozzles
- High production capacity and widerly application for different kinds of fabric
Specification:
Model | KTH-2600-8 |
Machine width | 2600mm |
Working width | 2400mm |
Chamber | 8 chamber |
Machine speed | 5-100m/min |
Heating system | Natural Gas/ Thermal oil |
Entry | Horizontal entry |
Padder | 2 roller's padder |
Automation | PLC+ Inverter control |
Operation system | Touch screen controller 15'' |
Air | Twin air system |
Company Introduction:
Wuxi Xinwen Machinery Manufacturing Co., Ltd is a high tech enterprise, specialist in stenter machine design, manufacturing and sales. Since 2000, we start and insist on giving a professional textile machinery solution for our customer, upgrade the product quality and create values for our customer
